10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
380 Operating Instructions, 04/2019, A5E36037884-007
Par. No.
Name
Unit
Data type
r2665
EPOS position setpoint
LU
I32
Description:
Displays the actual absolute position setpoint.
r29015
PTI: Pulse input frequency
Hz
Float
Description:
Displays the PTI input pulse frequency.
r29018[0...
1]
OA version
-
Float
Description: Displays the OA version.
Index:
• [0]: Firmware version
• [1]: Build increment number
r29400
Internal control signal status indicating
-
U32
Description:
Control signal status identifiers
• Bit 0: SON
• Bit 1: RESET
• Bit 2: CWL
• Bit 3: CCWL
• Bit 4: G-CHANGE
• Bit 5: P-TRG
• Bit 6: CLR
• Bit 7: EGEAR1
• Bit 8: EGEAR2
• Bit 9: TLIM1
• Bit 10: TLIM2
• Bit 11: CWE
• Bit 12: CCWE
• Bit 13: ZSCLAMP
• Bit 14: SPD1
• Bit 15 SPD2
• Bit 16: SPD3
• Bit 17: TSET
• Bit 18: SLIM1
• Bit 19: SLIM2
• Bit 20: POS1
• Bit 21: POS2
• Bit 22: POS3
• Bit 23: REF
• Bit 24: SREF
• Bit 25: STEPF
• Bit 26: STEPB
• Bit 27: STEPH
• Bit 28: EMGS
• Bit 29: C-MODE
