Parameters
10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
381
Par. No.
Name
Unit
Data type
r29942
DO signals status indicating
-
U32
Description:
Indicates the status of DO signals.
• Bit 0: RDY
• Bit 1: FAULT
• Bit 2: INP
• Bit 3: ZSP
• Bit 4: SPDR
• Bit 5: TLR
• Bit 6: SPLR
• Bit 7: MBR
• Bit 8: OLL
• Bit 9: WARNING1
• Bit 10: WARNING2
• Bit 11: REFOK
• Bit 12: CM_STA
• Bit 13: RDY_ON
• Bit 14: STO_EP
r29979
Index of actual electronic gear
-
U32
Description:
Displays the status of position loop.
• Bit 0 to Bit 1: Actual EGear index
