Insertion loss
Parameter
Description
Rated current
5 A
Noise frequency
(MHz)
0.15 0.5 1.0 5.0 10 30
CM (dB)
50
80
70
45
35
20
DM (dB) 50 75 65 55 55 40
Rated current
12 A
Noise frequency
(MHz)
0.15 0.5 1.0 5.0 10 30
CM (dB)
65
80
75
45
35
20
DM (dB)
60
70
70
60
50
30
Rated current
18 A
Noise frequency
(MHz)
0.15 0.5 1.0 5.0 10 30
CM (dB)
32
70
82
88
81
90
DM (dB)
40
67
68
72
69
59
Rated current
20 A
Noise frequency
(MHz)
0.15 0.5 1.0 5.0 10 30
CM (dB)
60
70
65
45
35
20
DM (dB)
55
65
60
50
45
40
