Siemens SIMOTICS S-1FL6 User Manual

General information
2.7 Technical data
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
73
Specific technical data
Article No. 1FL60...
42
44
61
62
64
66
67
90
92
94
96
Rated power [kW]
0.40
0.75
0.75
1.00
1.50
1.75
2.00
2.5
3.5
5.0
7.0
1)
Rated torque [Nm] 1.27 2.39 3.58 4.78 7.16 8.36 9.55 11.9 16.7 23.9 33.4
Maximum torque
[Nm]
3.8 7.2 10.7 14.3 21.5 25.1 28.7 35.7 50.0 70.0 90.0
Rated speed [rpm] 3000 2000 2000
Maximum speed
[rpm]
4000 3000 3000 2500 2000
Rated frequency [Hz]
200
133
133
Rated current [A]
1.2
2.1
2.5
3.0
4.6
5.3
5.9
7.8
11.0
12.6
13.2
Maximum current [A]
3.6
6.3
7.5
9.0
13.8
15.9
17.7
23.4
33.0
36.9
35.6
Moment of inertia
[10
-4
kgm
2
]
2.7 5.2 8.0 15.3/1
1.7
2)
15.3 22.6 29.9 47.4 69.1 90.8 134.3
Moment of inertia
(with brake) [10
-4
kgm
2
]
3.2 5.7 9.1 16.4/1
3.5
2)
16.4 23.7 31.0 56.3 77.9 99.7 143.2
Recommended load
to motor inertia ratio
Max. 10× Max. 5× Max. 5×
Operating tempera-
ture [°C]
0 to 40 (without power derating)
Storage temperature
[°C]
-20 to +65
Maximum noise level
[dB]
65 70 70
Oil seal lifetime [h]
5000
Encoder lifetime [h]
> 20000
4)
Degree of protection IP65, with shaft oil seal
Holding brake
Rated voltage (V)
24 ± 10%
Rated current (A)
0.88
1.44
1.88
Holding brake torque
[Nm]
3.5 12 30
Maximum brake
opening time [ms]
60 180 220
Maximum brake
closing time [ms]
45 60 115
Maximum number of
emergency stops
2000
3)
Oil seal lifetime [h]
5000
Encoder lifetime [h]
> 20000
4)
Degree of protection
IP65, with shaft oil seal
Weight of incremental encoder motor [kg]
With brake
2)
4.6/
4.8
6.4/
6.6
8.6/
8.8
11.3/
10.1
11.3/
11.5
14.0/
14.2
16.6/
16.8
21.3/
21.5
25.7/
25.9
30.3/
30.5
39.1/
39.3
