Siemens SIMOTICS S-1FL6 - Page 76

General information
2.7 Technical data
SINAMICS V90, SIMOTICS S-1FL6
74 Operating Instructions, 04/2019, A5E36037884-007
Article No. 1FL60...
42
44
61
62
64
66
67
90
92
94
96
Without brake
2)
3.3/
3.4
5.1/
5.2
5.6/
5.7
8.3/
7.0
8.3/
8.4
11.0/
11.1
13.6/
13.7
15.3/
15.4
19.7/
19.8
24.3/
24.4
33.2/
33.3
Weight of absolute encoder motor [kg]
With brake
2)
4.4/
4.5
6.2/
6.3
8.3/
8.4
11.0/
9.7
11.0/
11.1
13.6/
13.7
16.3/
16.4
20.9/
21.0
25.3/
25.4
29.9/
30.0
38.7/
38.8
Without brake
2)
3.1/
3.2
4.9/
5.0
5.3/
5.4
8.0/
6.7
8.0/
8.1
10.7/
10.8
13.3/
13.4
14.8/
14.9
19.3/
19.4
23.9/
24.0
32.7/
32.8
1)
When the surrounding temperature is between 30 °C and 40 °C, the 1FL6096 motors with brake will have a power
derating of 10%.
2)
The former value indicates the data for high inertia motors with straight connectors; the latter value indicates the data for
high inertia motors with angular connectors.
3)
Restricted emergency stop operation is permissible. Up to 2000 braking operations can be executed with 300% rotor
moment of inertia as external moment of inertia from a speed of 3000 rpm without the brake being subject to an inad-
missible amount of wear.
4)
This lifetime is only for reference. When a motor keeps running at 80% rated value and the surrounding temperature is
30 °C, the encoder lifetime can be ensured.
Note
The data of rated torque, rated power, and maximum torque in the above table allows a
tolerance of 10%.
