Meaning LED display
RDY RUN STOP SU/PF SF DP DP/
MPI
PN SY/MT OPT
Upgrade/downgrade of
DRIVE‑CLiQ components run‐
ning
0.5/1
(yel‐
low)
x x x x x x x x x
The upgrade/downgrade of
DRIVE‑CLiQ components is
completed (power OFF/ON of
the upgraded/downgraded de‐
vices is necessary)
2/1
(yel‐
low)
x x x x x x x x x
Underlicensing SINAM‐
ICS functions
5)
x x x x 0.5/1
(red)
x x x x x
PROFIBUS DP interfaces as master
No parameter assignment avail‐
able
x x x x x 0 0 x x x
At least one slave is missing x x x x x 1
(red)
1
(red)
x x x
Bus state "Clear" x x x x x 0.5/1
(green)
0.5/1
(green)
x x x
Bus state "Operate" x x x x x 1
(green)
1
(green)
x x x
PROFIBUS DP interfaces as i-slave
No parameter assignment avail‐
able
x x x x x 0 0 x x x
No parameter assignment mas‐
ter available
x x x x x 1
(red)
1
(red)
x x x
Bus state "Clear" x x x x x 0.5/1
(green)
0.5/1
(green)
x x x
Bus state "Operate" x x x x x 1
(green)
1
(green)
x x x
Upgrading SIMOTION devices (device update tool)
Downgrading requested x x x x Λ
(green)
x x x x x
Upgrade/downgrade running x x x x 0.5/1
(green)
x x x x x
Upgrade/downgrade comple‐
ted with error
x x x x Λ
(red)
x x x x x
Upgrade/downgrade comple‐
ted without error
x x x x 0
4)
x x x x x
Update data is being copied
from USB stick to CF card
0.5/1
(yel‐
low/
green)
x x x x x x x x x
Diagnostics
9.1 Diagnostics via LED displays
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B 383
