4.3 Opening the front cover
Introduction
The interfaces on the front side of the D4x5‑2 and the CX32‑2 have a cover. This is opened
by swinging the front cover down; the interface connections are then accessible and can be
wired.
A hinge connects the front cover to the front of the housing. Once opened, the cover can be
removed.
The front cover is closed by swinging it up; it automatically locks by means of a hook
at the top of the device housing.
Note
The cover of the D4x5-2 and CX32-2 can only be removed when it has been swung open
through approx. 45°.
Connecting
4.3 Opening the front cover
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B 61
