Note
With a CX32‑2, the shield is connected in the same way as the D4x5‑2. A CX32‑2 only has
the X122 terminal block and the shield connection element is narrower on a CX32‑2 than on
a D4x5‑2.
4.6.2 Connecting I/Os of the TB30
Pin assignment
$QDORJLQSXWVRXWSXWV
'LJLWDO,2V
3RZHUVXSSO\IRU
GLJLWDORXWSXWV
7%
;
;
;
Figure 4-9 Interface arrangement on the TB30
Additional references
Detailed
information about the pin assignment of the X424, X481 and X482 interfaces can be
found in the
SIMOTION D4x5‑2
Manual, Section "Supplementary system components".
Connecting
4.6 Connecting I/Os
SIMOTION D4x5-2
74 Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B
