Meaning LED display
RDY RUN STOP SU/PF SF DP DP/
MPI
PN SY/MT OPT
No CBE30-2 inserted x x x x x x x x x 0
CBE30-2 runs error-free x x x x x x x x x 1
(green
)
Bus error (CBE30-2):
●
Failure of a connected IO
device
● At least one of the assigned
IO devices cannot be
addressed
● Incorrect or no configuration
x x x x x x x x x 2/1
(red)
Firmware download running x x x x x x x x x 2/1
(green
)
Firmware download faulty x x x x x x x x x 0.5/1
(red)
1)
The LED state appears only very briefly due to the speed at which the "general reset" is completed. The module then
powers up (the STOP LED flashes yellow at 2 Hz).
2)
Copying is completed when the SF LED is steady green for at least 10 s.
3)
Both options depend on the LED state when activated via p0124[0] = 1.
4)
The upgrade or downgrade is complete when the SF LED goes out. The device then powers up automatically in the
upgraded or downgraded configuration (SF LED display then depends on the operating state of the device).
5)
In the case of SINAMICS licenses (e.g. SINAMICS DCB Extension), underlicensing of SINAMICS Integrated/CX32‑2 via
the flashing SF‑LED is indicated on the SIMOTION D Control Unit. An entry is also made in the diagnostic buffer and the
underlicensing is displayed in the license dialog box of SIMOTION SCOUT. The licensing is effected (like for SIMOTION
licenses) via SIMOTION SCOUT or via the SIMOTION license key on the CF card.
See also
For detailed information on the LED states, see Section
LED displays of the PROFINET
interface (Page 389).
Additional references
Further references can be found in the
Upgrading SIMOTION Devices
Operating Instructions.
Diagnostics
9.1 Diagnostics via LED displays
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B 385
