LED State Comment
RDY DP
Off Red FW checked
(no CRC error)
-
Red 0.5 Hz Red 0.5 Hz FW checked
(CRC error)
CRC invalid
Table 9-5 Firmware
LED State Comment
RDY DP
Yellow Not relevant Initializing –
Alternating Running See the table below
Table 9-6 CX32-2 – Description of the LEDs after ramp-up
LED Color State Description, cause Remedy
RDY
(READY)
- Off Electronic power supply is missing or outside the
permissible tolerance range.
Check power supply
Green Continuous
light
The component is ready for operation and cyclic
DRIVE‑CLiQ communication is taking place.
–
Flashing
0.5 Hz
Commissioning/reset –
Flashing
2 Hz
Writing to the memory card –
Red Flashing
2 Hz
General errors Check parameterization/con‐
figuration data
Red/
green
Flashing
0.5 Hz
CX32‑2 is ready for operation.
However, software licenses are missing.
Obtain licenses
Yellow Flashing
0.5 Hz
Firmware update of the connected DRIVE-CLiQ
components running
–
Flashing
2 Hz
DRIVE-CLiQ component firmware update com‐
plete.
Wait for POWER ON for the components in
question.
Perform POWER ON for the
respective component
Green/
yellow
or
red/yel‐
low
Flashing
2 Hz
Component detection via LED is activated
(p0124[0]).
Note:
Both
options depend on the LED state when com‐
ponent detection is activated via p0124[0] = 1.
–
Diagnostics
9.1 Diagnostics via LED displays
SIMOTION D4x5-2
394 Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B
