SLE / SLE-DP – SIMOLINK-Encoder 02.2001 Anhang
GWE-477 763 4070.76 J Siemens AG
Betriebsanleitung SIMOVERT MASTERDRIVES
Anhang C: GSD-Datei
;==========================================================
; GSD-File for SIMOLINK Encoder SLE-DP SIEMENS AG
; MLFB : 6SX7005-0AG01
;
; Stand : 23.03.2000 / I.II
; File : SIEM80A9.GSD
; Version: V1.0
;===========================================================
#Profibus_DP
GSD_Revision=1
;General parameters
Vendor_Name="Siemens AG ATD TD 6 EPG"
Model_Name="SIMOLINK SLE-DP"
Revision="Ausgabestand 01"
OrderNumber="6SX7005-0AG01"
Ident_Number=0x80A9
Protocol_Ident=0
Station_Type=0
FMS_supp=0
Hardware_Release="V2.0"
Software_Release="-"
9.6_supp=1
19.2_supp=1
93.75_supp=1
187.5_supp=1
500_supp=1
1.5M_supp=1
3M_supp=1
6M_supp=1
12M_supp=1
MaxTsdr_9.6=60
MaxTsdr_19.2=60
MaxTsdr_93.75=60
MaxTsdr_187.5=60
MaxTsdr_500=100
MaxTsdr_1.5M=150
MaxTsdr_3M=250
MaxTsdr_6M=450
MaxTsdr_12M=800
Implementation_Type="LSPM2"
Repeater_Ctrl_Sig=2
24V_Pins=0
; Slave-Specification:
Slave_Family=0
Freeze_Mode_supp=1
Sync_Mode_supp=1
Set_Slave_Add_Supp=0
Auto_Baud_supp=1
Min_Slave_Intervall=50
Max_Diag_Data_len=13
Modular_Station=0
; UserPrmData: Length and Preset:
User_Prm_Data_Len=5
User_Prm_Data=0x00,0x00,0x00,0x00,0x00
; Module Definition List
Module="Module 2 Byte OUT / 2 Byte IN" 0xA1,0x91
EndModule
