Software Requirements
3.1 Converter
Connecting SIMOVERT MASTERDRIVES MC to the Technology-CPU
Product Information, 03/2008, A5E00272072-05
11
3. Enter the path for the bootstrap file, the program file and the slot in which the CBP2 is
installed. Activate the Activate diagnostics checkbox.
Note
You can download the current firmware version from the Internet:
http://support.automation.
siemens.com
Entry ID 10999663
Figure 3-3 Settings in the Option Card Download window
4. Right-click a free area of the screen.
The following window opens:
Figure 3-4 Additional settings for the download
5. Enter a program length of 128KB and 8 EEPROM blocks.
