Commissioning
4.3 Creating a STEP 7 project
Connecting SIMOVERT MASTERDRIVES MC to the Technology-CPU
Product Information, 03/2008, A5E00272072-05
49
4.3.3 Referencing
Defining the referencing mode
If the connected axis is to be referenced, the referencing mode must be specified in both the
Technology-CPU and MASTERDRIVES MC.
Referencing mode "External zero mark only"
Operational sequence:
● When a defined edge of the external zero mark is crossed, the position is accepted.
Hardware structure:
 
9'&
//
0
&387'3
352),%86'3
0$67(5'5,9(60&
%(52
(QFRGHUV
,QSXWWHUPLQDO
;
5HIHUHQFHSRWHQWLDO
WHUPLQDO;
Figure 4-28 Referencing (External zero mark only)
