Commissioning
4.3 Creating a STEP 7 project
Connecting SIMOVERT MASTERDRIVES MC to the Technology-CPU
36 Product Information, 03/2008, A5E00272072-05
Technology CPU
The settings of the encoder used that are required for the Technology CPU are listed in the
following table. Only the input values listed in the tables are evaluated for the respective
encoder.
If a fine resolution 0 (standard) is set in the Technology CPU, this means a fine resolution of
2
11
= 2048. If a different value is set (e.g. 1024), this means the actual fine resolution.
Encoder parameters in SIMOTION are specified using parameters in the axis configuration
windows or using the configuration data in the expert list as
"TypeOfAxis.NumberOfEncoders.Encoder_1.xxx". The following assignments apply to the
axis configuration windows:
Parameter Meaning
Encoder type TypeOfAxis.NumberOfEncoders.Encoder_1.encoderType
Encoder mode TypeOfAxis.NumberOfEncoders.Encoder_1.encoderMode
Resolution TypeOfAxis.NumberOfEncoders.Encoder_1.IncEncoder.IncResolution
TypeOfAxis.NumberOfEncoders.Encoder_1.AbsEncoder.AbsResolution
Number of data bits TypeOfAxis.NumberOfEncoders.Encoder_1.AbsEncoder.AbsDataLength
Multiplication factor of
the cyclic encoder
actual value
TypeOfAxis.NumberOfEncoders.Encoder_1.IncEncoder.IncResolutionMultiplierCyclic
TypeOfAxis.NumberOfEncoders.Encoder_1.IncEncoder.AbsResolutionMultiplierCyclic
Multiplication factor of
the absolute encoder
actual value
TypeOfAxis.NumberOfEncoders.Encoder_1.AbsEncoder.AbsResolutionMultiplierAbsolute
