Status
3. Select SS1
3.1. Select SS1 while the motor is switched on.
Test each configured activation, e.g. via digital inputs and PROFIsafe.
3.2. In your machine, check the following:
● The motor brakes on the OFF3 ramp.
● SS1 is active (r9773.6 = 1).
● After the p9652 time has expired, the inverter signals: "STO is active"
(r9773.1 = 1).
4. Deselect SS1
4.1. Deselect SS1.
4.2. Check the following:
● SS1 is not active (r9773.6 = 0).
● The inverter signals neither faults nor alarms of the safety functions
(r0945[0…7], r2122[0…7]).
You have completed the acceptance test of the SS1 function.
Appendix
A.2 Examples of acceptance tests
