03.04 "Parameters" Operating Area
5.1 Tool data
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-169
Milling tool with adapter
FF'
Entries in
tool parameters
DP3
DP6
DP21
Length 1
-Geometry
Radius
-Geometry
Length
-Adapter
Wear values
according to
requirement
Other values must
be set to zero
DP1 1xy
G17:
G18:
G19:
F´- Toolholder
reference point
F-Adapter reference point (when tool is
inserted = toolholder reference point)
Effect
Length 1
Length 1 total
Length 1 adapter
Length 1 in Z
Radius in X/Y
Length 1 in Y
Radius in Z/X
Length 1 in X
Radius in Y/Z
Group type 2xy (drills):
200 Twist drill
205 Drill
210 Boring bar
220 Center drill
230 Countersink
231 Counterbore
240 Tap regular thread
241 Tap fine thread
242 Tap Whitworth thread
250 Reamer
Required offset values
for a drill
F
Entries in
tool parameters
DP1
DP3
2xy
Length 1
Wear values
according to
requirement
Other values must
be set to zero
Effect
G17: Length 1 in Z
Length 1 in Y
Length 1 in X
G18:
G19:
F - Toolholder
reference point
Length 1
