Siemens SINUMERIK 840D sl Configuration Manual

Setting Can be found at Further information
Default F-monitoring time for
F-peripherals of this interface
Interface > F-parameters
● Information system, keyword
"Monitoring and response
times"
F-monitoring time Module/submodule > F-parame‐
ters
● Information system, keyword
"Configuring the F-peripherals"
● Information system, keyword
"Monitoring and response
times"
I/O address Module/submodule > I/O address‐
es
● Information system, keyword
"Addressing modules (S7-300,
S7-400)"
Size of the PLC process im‐
age
PLC > Cycle
● Information system, keyword
"Settings for the cycle behavior
(S7-300, S7-400)"
● Information system, keyword
"S7-300 memory areas"
Name of an I/O system node Device / header module > General
● Information system, keyword
"Assign device name and IP
address"
IP address of an I/O system
node
Device / header module > PROFI‐
NET interface > Ethernet address‐
es
● Information system, keyword
"Assign device name and IP
address"
NCU properties
The Safety Integrated mode of the NCU affects not only the configuration of the integrated PLC,
but rather also that of the integrated drives.
SINAMICS Integrated and NX modules always use automatically the same Safety Integrated
mode as the associated NCU.
Therefore, set this mode in the NCU properties and not in the PLC properties:
Safety configuration
10.4 Parameterization of relevant properties
SINUMERIK STEP 7 Toolbox V15.1
Configuration Manual, 12/2018, A5E46279635B AA 179

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
