3.6 Creating SINUMERIK PLC archives
3.6.1
Creating a SINUMERIK PLC archive
Introduction
Unlike TIA Portal project archives (*.zap*), SINUMERIK PLC archives (*.arc) contain
precompiled commissioning data that you can import directly to the NCU (e.g. with SINUMERIK
Operate).
A SINUMERIK archive offers the following possibilities:
● Direct image of the data of a PLC taken into operation in a file
● Simplification of the series commissioning
● Commissioning of the PLC with the SINUMERIK archive directly on the NCU without using
a PG/PC, TIA Portal or STEP 7
● Transfer of the data to the NCU without establishing an online connection to the actual
hardware
SINUMERIK archives (*.arc) have nothing in common with TIA Portal project archives (*.zap*).
TIA Portal project archives are compressed files, each of which contains a complete project,
including the complete folder structure of the project. (See: Online help, keyword "TIA Portal
project archive").
You can create a PLC archive with the SINUMERIK Toolbox and load it to the NCU (e.g. with
SINUMERIK Operate) in order to simplify the actual commissioning.
You can create the following SINUMERIK archives:
Archive type Command in the TIA
Portal
Data included
PLC hardware upgrade ar‐
chive (Page 48
)
Only hardware...
● Hardware data (SDB) of the PLC
PLC commissioning ar‐
chive (Page 50
)
Hardware and all pro‐
gram blocks...
● Hardware data (SDB) of the PLC
● Program blocks of the PLC
● Hardware data (SDB) of the CP
PLC reload archive
(Page 52)
Selected program
blocks...
● Program blocks of the PLC
Note
Editing SINUMERIK archives (.arc)
After you have created a SINUMERIK archive, you can open and edit it with various tools.
See: External tools for SINUMERIK archives
(Page 48)
Configuring the NCU
3.6 Creating SINUMERIK PLC archives
SINUMERIK STEP 7 Toolbox V15.1
44 Configuration Manual, 12/2018, A5E46279635B AA
