Procedure overview
Table 4-10 Example procedure for creating and loading PLC symbols
Step Description
1 If necessary, check or edit symbols in the TIA Portal
● You can change the symbolic names of blocks by right-clicking the block and selecting
"Rename" from the shortcut menu.
● You can change symbols of the individual elements in the block editor.
● PLC variables for Flags, Times, Input, Output, Timer and Counter can be changed in the
associated table field (e.g. under "CNC_1 > PLC 1 > PLC variables > Display all variables")
2 Exporting PLC symbols with the TIA Portal (Page 86)
3 If necessary, make export files available on the NCU or PCU, e.g. using a USB FlashDrive
4 Importing PLC symbols in SINUMERIK Operate (Page 89)
4.10.2 Exporting PLC symbols
Note
Deleting unwanted blocks before exporting PLC symbols
If you have saved unwanted blocks in your project, this lengthens the time required for
exporting and importing PLC symbols.
Consequently, delete unwanted blocks that you copied previously from the basic program
library prior to the export.
See: General information about the PLC program (Page 55)
Programming the PLC
4.10 Exporting PLC symbols for SINUMERIK Operate
SINUMERIK STEP 7 Toolbox V15.1
86 Configuration Manual, 12/2018, A5E46279635B AA
