Siemens SINUMERIK 840D sl Configuration Manual

Basic procedure
● Activate the SINUMERIK Safety Integrated plus (F-PLC) mode in the NCU properties
(Page 175).
● With the activation of the F-capability of the NCU, among other things, an F-execution group
is created and telegrams are inserted for PROFIsafe and SIC/SCC.
● Add the desired components (e.g. peripheral device, drive device, NX module, etc.).
● In the network view, interconnect the peripheral device or drive device with the PROFINET
interface X150 of the NCU.
● Check the PROFIsafe addresses. (Page 208)
● If necessary, set the F-monitoring time manually.
● Assign the F-destination addresses. The procedure depends on the associated device.
Information on the commissioning steps to be carried out in SINUMERIK Operate and on
acceptance can be found in the SINUMERIK Safety Integrated plus Commissioning Manual.
See also
Programming and operating manual "SIMATIC Safety - Configuring and Programming" (
https://
support.industry.siemens.com/cs/products?search=SIMATIC
%20Safety&dtp=Manual&pnid=24471)
10.8.3 Creating a second F-runtime group for Safety Integrated plus (F-PLC)
An F-runtime group is automatically created when you activate Safety Integrated plus (F-PLC)
mode. The "Program blocks" folder contains the created F-blocks of the F-runtime group:
CYC_INT5 [OB35], Main-Safety [FB1010] and Main-Safety_DB [DB1010].
The procedure how you can create a second F-runtime group is described below, e.g. to
organize fast-running safety-oriented program sections in a dedicated F-runtime group.
Characteristic SINUMERIK-specific features are described in particular. Detailed information
can be found in the SIMATIC Safety help, Chapter "Defining F-runtime groups".
Procedure
To create a second F-runtime group, proceed as follows:
1. In the project tree, double-click the command "Safety administration", e.g. under "CNC_1 >
PLC_1".
2. In the Safety Administration Editor, select the "F-runtime group" entry in the sector tree.
Safety configuration
10.8 Configuring Safety Integrated plus (F-PLC)
SINUMERIK STEP 7 Toolbox V15.1
204 Configuration Manual, 12/2018, A5E46279635B AA

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
