10.4 Parameterization of relevant properties
The
Safety Integrated modes of the NCU control the safety behavior of the NCU together with
the integrated subcomponents, such as the PLC, SINAMICS Integrated and possibly
connected NX modules. Depending on the used mode and communications standard
(PROFINET or PROFIBUS), you must configure further relevant properties and F-parameters
for various modules. Sample configuring sequences can be found in Sections Configuring
Safety Integrated (SPL) (Page 187) and Configuring Safety Integrated plus (F-PLC)
(Page 201).
You can, however, also parameterize the appropriate properties in a different order.
Overview
The following table shows in which device properties and in which section you find a specific
configuration-relevant setting:
Note that not all parameters are relevant in both Safety Integrated modes. In addition, some
parameters are displayed only in a specific Safety Integrated mode for the SINAMICS
Integrated and NX components and the associated telegrams.
Table 10-1 Configuration-relevant properties
Setting Can be found at Further information
Safety Integrated mode (op‐
erating mode)
NCU > Safety Integrated
● This
chapter, "NCU properties"
section.
● Changing the Safety
Integrated mode (Page 175)
● Safety Integrated mode (SPL)
● Safety Integrated plus mode (F-
PLC)
Basis for PROFIsafe ad‐
dresses
PLC > Fail-safe > F-parameters
● Information system, keyword
"Basis for PROFIsafe
addresses".
F-source address
(F_Source_Add)
PLC > Fail-safe > F-source ad‐
dresses
(only for Safety Integrated mode
(SPL))
(for a GSD module, also under
"Module > PROFIsafe")
● Configuration of the
PROFIsafe addresses
(peripherals)
● Configuration of the
PROFIsafe addresses (drives)
● Information system, keyword
"Special considerations when
configuring the F-system"
F-
destination address
(F_Dest_Add)
Module/submodule > F-parame‐
ters
● Information system, keyword
"Special considerations when
configuring the F-system"
DIL switching setting Module/submodule > F-parame‐
ters
● Configuring Safety Integrated
plus (F-PLC) (handling
overview)
● Configuring Safety Integrated
(SPL) (handling overview)
Safety configuration
10.4 Parameterization of relevant properties
SINUMERIK STEP 7 Toolbox V15.1
178 Configuration Manual, 12/2018, A5E46279635B AA
