4
Machine Operating Area 03.04
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
4-162 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Operating sequence
"AUTO" or "MDI" mode is selected in the "Machine" operating area.
Program
control
Press the horizontal softkey "Program control"
Another window pane appears in the "program control" window. The
softkey menus change and the softkeys of the skip blocks and block
display appear in the vertical menu.
Each actuation of the "toggle key" activates or deactivates the
selected program control function.
Skip blocks, SW 6.3 and
higher
The block display in software versions 6.3 and higher appears in an
extended "program control" window pane and can be selected with
the vertical softkey "Block display".
Skip
blocks
Press the vertical softkey "Skip blocks"
The vertical softkey "Skip blocks" is only displayed if more than 1 skip
level was set in MD 9423: MA_MAX_SKP_LEVEL. The levels to be
skipped can only be changed when the control is in the Stop/Reset
state.
Place the cursor at the required position.
Each actuation of the "toggle key" activates or deactivates the
selected skip level in the "program control" window.
Other information
The entries influence the program control display (see Section 2.5).
The program control display is output irrespective of the selected
menu.
For further information about how to program skip levels, please see:
References: /PG/, Programming Guide, Fundamentals
