"Program" Operating Area 03.04
6.9 Pro
g
ram simulation
6
Ó Siemens AG, 2004. All rights reserved
6-316 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
<<
Return to main simulation menu
Menu "Details..." 3D
vertical
"3D view" (3D with tool data) for milling, not effective for turning
simulation
Standard 3D view, orientation top/front
3D view, orientation top/left, rotated clockwise by 90°
3D view, orientation top/right, rotated clockwise by 90°
Fit to
size
3D view, orientation bottom/front, inclined towards top
Automatic screen size adaptation
Also possible with "ENTER" or "INPUT" key.
Zoom...
<<
Show window pane border in active window
(size can be altered with "+"- and "-" keys, position with "cursor" keys)
Return to main simulation menu
