Siemens SINUMERIK 880 GA2 Programming Guide

01.93 4 Programming of Motion Blocks
4.2.15 Program coordination
Mode group 1
Mode group 2
Channel 1 Channel 2
X2
Z2
T2
(S1)
Mode group 3
Channel 4
X4
Y4
Z4
Channel 1
MPF 11
[INIT MPF,12,2]
[INIT MPF,13,3]
[INIT MPF,14,4]
[START 2,3]
.
.
.
.
[WAIT M,10,2,3]
[START 4]
M30
Channel 2
MPF 12
.
.
.
.
[WAIT M,8,3]
.
[WAIT M,9,3]
.
[WAIT M,10,1,3]
.
M30
Channel 3
MPF 13
.
.
.
.
[WAIT M,8,2]
.
.
[WAIT M,9,2]
[WAIT M,10,1,2]
.
M30
Channel 4
MPF 14
.
.
.
.
.
.
.
.
.
.
M30
Channel 3
X3
Z3
C3
T3
S3
(S1)
© Siemens AG 1991 All Rights Reserved 6ZB5 410-0HD02 4–49
SINUMERIK 880, (PG)
