05.91 4 Programming of Motion Blocks
4.1.1 Axis motion without machining G00
Example:
N05 G00 G90 X30 Y20
L
F
G00
W X4020
Y
20
10
30
10 30 50
4.2 Axis motions with machining
The control implements linear interpolation or circular interpolation depending on the type of
axis motion:
Linear interpolation: Linear motion
paraxial
in two axes
in three axes
in four axes
in five axes
Circular interpolation: Circular motion in 2 axes (plane)
© Siemens AG 1991 All Rights Reserved 6ZB5 410-0HD02 4–3
SINUMERIK 880, (PG)
