05.91 2 Fundamentals of Programming
2.7 Input/output formats
2.7 Input/output formats
Program Leader
% MPF 1234
L
F
Part program 1234 (MAIN PROGRAM FILE)
(Perform measurem.)
N...
L
F
N...
L
F
Remark
Part program
M02
L
F
(M30
L
F
) End of part program
Subroutines Leader
% SPF 234
L
F
Subroutine 234 (SUB PROGRAM FILE)
N1...
L
F
N2...
L
F
Subroutine
(Drill cycle)...
L
F
Remark
M17
L
F
End of subroutine
%ZOA 0
L
F
Settable zero offsets (ZERO OFFSET ACTIVE)
G 154X=...Z=...
L
F
:
G 157X=...Z=...
L
F
G 254X=...Z=...
L
F
:
G 257X=...Z=...
L
F
1st to 4th settable offset coarse
(axis-specific)
1st to 4th settable offset fine
(axis-specific)
M02
L
F
(M30
L
F
) Zero offset End of data block
%ZOA 1...16 Angle of rotation, channel-specific
G 154A=
:
G157A=
M02
L
F
(M30
L
F
)
© Siemens AG 1991 All Rights Reserved 6ZB5 410-0HD02 2–11
SINUMERIK 880, (PG)
