7 Parameters 05.91
7.3 Parameter calculations
Examples:
N35 R1 = 9.7 R2 = – 2.1
L
F
N40 X = 20.3+R1
L
F
N45 Y = 32.9 – R2
L
F
N50 Z = 19.7 – R1
L
F
Result: X = 30
Y = 35
Z = 10
• Equation with numbers and parameters
It is possible to multiply, divide, add and subtract absolute numbers and R parameters.
R10 = 15+ R11
• Several separate equations can be programmed in one block.
R1 = R2 + 23 R50 = R37 · 3 R99 = R27 / R13
L
F
7–4 © Siemens AG 1991 All Rights Reserved 6ZB5 410-0HD02
SINUMERIK 880, (PG)
