05.91 10 Cutter Radius Compensation (CRC), Tool Nose Radius Compensation (TNRC)
10.8 M00, M01, M02 and M30 with CRC/TNRC selected
No path with G40 or programming of one axis in the final block:
X
Y
N30
50
S
(N30)
S
(N35)
N35
50
R
R
N30 X50 Y50
L
F
N35 Y0
L
F
N40 G40
L
F
The compensation is not withdrawn.
N45 M30
L
F
G40 in the penultimate block or programming of two axes in the final block:
N30
Y
X
N35
50
S
(N30)
S
(N30)
50
R
N30 X50 Y50
L
F
N35 G40 Y0
L
F
N40 M30
L
F
The compensation is withdrawn in N35.
