WARNING
Incorrect selection of type of protection
Risk of explosion in areas subject to explosion hazard.
This device is approved for several types of protection.
1. Decide in favor of one type of protection.
2. Connect the device in accordance with the selected type of protection.
3. In order to avoid incorrect use at a later point, make the types of protection that are not used
permanently unrecognizable on the nameplate.
Two-wire mode
NOTICE
Connection of voltage source to current input
Device damage if a voltage source is connected to the current input I
w
(terminals 6 and 7).
• Never connect the current input I
w
to a low-resistance voltage source, otherwise the
positioner may be destroyed.
• Always use a high-impedance power source.
• Observe the static destruction limit specied in the "Technical specications (Page61)".
Note
Improvement of interference immunity
• Lay signal cables separate from cables with voltages > 60V.
• Use cables with twisted wires.
• Keep the device and the cables at a distance from strong electromagnetic elds.
• Observe the communication conditions described in the section Technical specications
(Page61).
• Use shielded cable to guarantee the full specication according to HART.
5.2 Grounding
The positioner is grounded via the mounting kit or via grounding with thread M4 on the
enclosure, ⑨ in the gure "Overview of the device components (Page7)".
Connecting
5.2Grounding
SIPART PS100
32 Operating Instructions, 06/2023, A5E50188938-AF
