Technical speci󹪝cations
11
11.1 Input
Analog input (AI), terminal 6 and 7 
Nominal signal range 4... 20mA
Minimum current to maintain the operation 3.8mA
Maximum load voltage 4...20mA 6.5V corresponds to 325Ω at 20mA
Maximum load voltage HART 8.4V corresponds to 420Ω at 20mA
Static destruction limit ±40mA
Type of communication HART7
Digital input (DI), terminals 9 and 10 
Galvanic isolation Galvanically connected to analog input
Galvanically isolated from the outputs
Signal status 0, 󹪞oating contact open >300kΩ
Signal status 1, 󹪞oating contact closed <3kΩ
Contact load Can only be used for 󹪞oating contact;
Max. contact load <20μA, 3V
11.2 Output
Analog output (AO), terminals 61 and 62 
Wiring con󹪝guration 2-wire connection
Nominal signal range 4...20mA
Fault current <3.6mA
Supply voltage U
H
12...30V
External load R
B
[kΩ] ≤(U
H
[V] - 12V)/20mA
Resolution in relation to the nominal signal range 0.05%
Maximum transmission error in relation to the nominal signal
range
±0.3%
Maximum e󹪜ect of ambient temperature ±0.1%/10K
Maximum residual ripple ±0.5%
Galvanic isolation Galvanically isolated from the other electrical inputs and
outputs
SIPART PS100
Operating Instructions, 06/2023, A5E50188938-AF 61
