Local operation
6
Navigating in "NO INIT" operation mode
 




  
Initializing

 Con󹪝guring

  
  Valve
open / close
   
① Operation mode and setpoint in percent
② Angle of position detection in degrees
③ Info (Page50)
④ Symbols for device status (Page49)
Navigating in "AUTO" and "MANUAL" operation mode
  AUTO    MANUAL 
 


 




MANUAL

 Con󹪝guring

AUTO  Con󹪝guring
  No
function
    Valve
open / close

① Operation mode and setpoint in percent
② Valve position as a percentage
③ Info (Page50)
④ Symbols for device status (Page49)
SIPART PS100
Operating Instructions, 06/2023, A5E50188938-AF 37
