Mechanical construction 
 With sealant 6Nm (4.4ftlb)
• M20 cable gland, plastic
4Nm (3ftlb)
• M20 cable gland, metal
6Nm (4.4ftlb)
• Cable gland 1/2-14NPT metal
15 Nm (11.1 ft lb)
• Cable gland for NPT bushing in the NPT adapter
NOTE: To avoid damage to the device, the NPT adapter must
be held in place while the NPT gland is screwed into the NPT
adapter.
68 Nm (50 ft lb)
• Screw cap made of plastic
2.5Nm (1.8ftlb)
• Screw cap made of metal
4Nm (3ftlb)
• Pressure gauge block 󹪝xing screws
6Nm (4.4ftlb)
Pressure gauge 
• Material pressure gauge
Plastic, Mechanics brass
Stainless steel, Mechanics brass nickel-plated
Stainless steel, Mechanics stainless steel 316
• Material pressure gauge block
Anodised aluminium
Stainless steel 316
• Degree of protection

 Plastic, Mechanics brass, Pressure gauge block anodised
aluminium
IP31
Stainless steel, Mechanics brass nickel-plated, Pressure
gauge block anodised aluminium
IP44
Stainless steel, Mechanics stainless steel 316, Pressure
gauge block stainless steel 316
IP54
Connections, electrical 
• Screw terminals
2.5mm
2
AWG30-14
• Cable gland
M20x1.5 or 1/2-14NPT with NPT adapter
Connections, pneumatic G¼ or ¼-18 NPT
11.6 Controller
Controller  
Control unit  
• Five-point controller
Adaptive 
• Deadband
 
 Adjustable peak value ±0.1 to 3%, plus hysteresis (half of the dead‐
band, but at least 0.2%)

Minimization of the peak value Always active 
Analog input (AI), terminal 6 and 7  
• Sampling interval
50ms 
Technical speci󹪝cations
11.6Controller
SIPART PS100
64 Operating Instructions, 06/2023, A5E50188938-AF
