Getting started
1
Requirement
You have read the following safety instructions:
• General safety notes (Page15)
• Basic safety notes: Installing/mounting (Page19)
• Basic safety notes: Connecting (Page29)
• Basic safety notes: Commissioning (Page39)
Read the entire document for information on getting the best performance from your device.
Procedure
① Circuit diagram on module cover ⑦ Exhaust air outlet with a sound absorber
② Display ⑧ Connecting terminals
③ Output: Actuating pressure Y1 ⑨ Grounding, thread M4
④ Input: Supply pressure PZ ⑩ Lower cable gland, thread M20x1.5
⑤ Output: Actuating pressure Y2 for double-
acting actuators
⑪ Upper cable gland, thread M20x1.5
⑥ Buttons
Figure1-1 Overview of device components, open cover
SIPART PS100
Operating Instructions, 06/2023, A5E50188938-AF 7
