SIPROTEC
®
4 Devices
4-10
7SA6 Manual
C53000-G1176-C156-2
Display on
the Device
To display messages in the operating field of the SIPROTEC
®
4 device:
• Select Main Menu → Annunciation →
e.g. Event Log or Trip Log.
Figure 4-4 SIPROTEC
®
4, device display of operating messages in the event log — ex-
ample
Figure 4-5 SIPROTEC
®
4, device display of fault messages— example
ANNUNCIATION 01/05
---------------------
>Event Log –> 01
>Trip Log –> 02
MAIN MENU 01/05
---------------------
>Annunciation –> 1
>Measurement –> 2
EVENT LOG 19/19
---------------------
06.19.98 11:52:05,461
Reset LED ON
TRIP LOG 01/08
---------------------
>Last Fault –> 1
>2nd Last Fault –> 2
LAST FAULT 01/10
---------------------
06.22.98 23:49:34.845
Network Fault 6 ON
To Next Page
