Functions
6-2117SA6 Manual
C53000-G1176-C156-2
Address 3466 2.AR Tdead 3Flt; dead time after 3-phase starting
Address
3467 2.AR Tdead1Trip; dead time after 1-pole tripping
Address
3468 2.AR Tdead3Trip; dead time after 3-pole tripping
Address
3469 2.AR: Tdead EV.;deadtimeincaseofsequentialfault
Address
3470 2.AR: CB? CLOSE; check CB ready before reclosure
Address
3471 2.AR SynRequest; sync. check after 3-pole tripping
For the 3rd cycle:
Address
3472 3.AR: START; determines if starting in 3rd cycle is allowed at all
Address
3473 3.AR: T-ACTION; action time for the 3rd cycle
Address
3475 3.AR Tdead 1Flt; dead time after 1-phase starting
Address
3476 3.AR Tdead 2Flt; dead time after 2-phase starting
Address
3477 3.AR Tdead 3Flt; dead time after 3-phase starting
Address
3478 3.AR Tdead1Trip; dead time after 1-pole tripping
Address
3479 3.AR Tdead3Trip; dead time after 3-pole tripping
Address
3480 3.AR: Tdead EV.;deadtimeincaseofsequentialfault
Address
3481 3.AR: CB? CLOSE; check CB ready before reclosure
Address
3482 3.AR SynRequest; sync. check after 3-pole tripping
For the 4th cycle:
Address
3483 4.AR: START; determines if starting in 4th cycle is allowed at all
Address
3484 4.AR: T-ACTION; action time for the 4th cycle
Address
3486 4.AR Tdead 1Flt; dead time after 1-phase starting
Address
3487 4.AR Tdead 2Flt; dead time after 2-phase starting
Address
3488 4.AR Tdead 3Flt; dead time after 3-phase starting
Address
3489 4.AR Tdead1Trip; dead time after 1-pole tripping
Address
3490 4.AR Tdead3Trip; dead time after 3-pole tripping
Address
3491 4.AR: Tdead EV.;deadtimeincaseofsequentialfault
Address
3492 4.AR: CB? CLOSE; check CB ready before reclosure
Address
3493 4.AR SynRequest; sync. check after 3-pole tripping
5thto8th
reclosure cycles
If more than 4 cycles have been selected during the configuration of the scope of func-
tions (section 5.1), the cycles following the fourth cycle operate with the same settings
asthefourthcycle.
6.14.3 Settings
Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings“.
Addr. Setting Title Setting Options Default Setting Comments
3401 AUTO RECLOSE OFF
ON
ON Auto-Reclose function
3402 CB? 1.TRIP YES
NO
NO CB ready interrogation at 1st trip
3403 T-RECLAIM 0.50..300.00 sec 3.00 sec Reclaim time after successful
AR cycle
3404 T-BLOCK MC 0.50..300.00 sec; 0 1.00 sec AR blocking duration after
manual close
3406 EV. FLT. RECOG. with Pickup
with Trip
with Trip Evolving fault recognition
