Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings“.
6.2.2.6 Information Overview
Addr. Setting Title Setting Options Default Setting Comments
1601 PROGAM U/I Ph-E: Uphe/ Ph-Ph: Uphph
Ph-E: Uphph/Ph-Ph: Uphph
Ph-E: Uphe/Ph-Ph: Uphe
Ph-E: Uphe/Ph-Ph: I>>
Ph-E: Uphe/ Ph-Ph:
Uphph
Pickup program U/I
1602 DELAY FORW. PU 0.00..30.00 sec; ∞ 1.20 sec Trip delay for Forward-PICKUP
1603 DEL. NON-DIR PU 0.00..30.00 sec; ∞ 1.20 sec Trip delay for non-directional
PICKUP
1630A 1ph FAULTS phase-earth
phase to phase only
phase-earth 1ph-pickup loop selection (PU
w/o earth)
1610 Iph>> 0.25..10.00 A 1.80 A Iph>> Pickup (overcurrent)
1611 Iph> 0.10..4.00 A 0.20 A Iph> Pickup (minimum current)
1612 Uph-e (I>>) 20..70 V 48 V Undervoltage (ph-e) at Iph>>
1613 Uph-e (I>) 20..70 V 48 V Undervoltage (ph-e) at Iph>
1614 Uph-ph (I>>) 40..130 V 80 V Undervoltage (ph-ph) at Iph>>
1615 Uph-ph (I>) 40..130 V 80 V Undervoltage (ph-ph) at Iph>
1616 Iphi> 0.10..8.00 A 0.50 A Iphi> Pickup (minimum current
at phi>)
1617 Uph-e (Iphi>) 20..70 V 48 V Undervoltage (ph-e) at Iphi>
1618 Uph-ph (Iphi>) 40..130 V 80 V Undervoltage (ph-ph) at Iphi>
1619A EFFECT ϕ forward and reverse
Forward
forward and reverse Effective direction of phi-pickup
1620 ϕ > 30..60 ° 50 ° PHI> pickup (lower setpoint)
1621 ϕ < 90..120 ° 110 ° PHI< pickup (upper setpoint)
F.No. Alarm Comments
3781 Dis.TimeOut Tfw DistanceTime Out Forward PICKUP
3782 Dis.TimeOut Tnd DistanceTime Out Reverse/Non-dir. PICKUP
3695 Dis Pickup ϕ L1 Dist.:PhiphaseL1Pickup
3696 Dis Pickup ϕ L2 Dist.:PhiphaseL2Pickup
3697 Dis Pickup ϕ L3 Dist.:PhiphaseL3Pickup
