Functions
6-1617SA6 Manual
C53000-G1176-C156-2
be used “>DTT Trip L1”, “>DTT Trip L2”and“>DTT Trip L3”. Figure6-90 there-
fore also applies in this case.
6.10.2 Applying the Function Parameter Settings
A prerequisite for the application of the direct and remote tripping functions is that dur-
ing the configuration of the scope of functions in the device (Section 5.1) the setting in
address
122 DTT Direct Trip = Enabled was applied. In address 2201 DTT Di-
rect Trip ON
or OFF, it is furthermore possible to switch the function on or off.
It is possible to set a trip delay for both the local external trip and the receive side of
theremotetripinaddress
2202 Trip Time DELAY. This can be used as a security
time margin, especially in the case of local trip.
Once a trip command has been issued, it is maintained for at least as long as the set
minimum trip command duration
TMin TRIP CMD, which was set for the device in
general in address 240A (Sub-section 6.1.1). Reliable operation of the circuit breaker
is therefore ensured, even if the initiating signal pulse is very short.
6.10.3 Settings
6.10.4 Information Overview
Addr. Setting Title Setting Options Default Setting Comments
2201 FCT Direct Trip ON
OFF
OFF Direct Transfer Trip (DTT)
2202 Trip Time DELAY 0.00..30.00 sec; ∞ 0.01 sec Trip Time Delay
F.No. Alarm Comments
4403 >BLOCK DTT >BLOCK Direct Transfer Trip function
4412 >DTT Trip L1 >Direct Transfer Trip INPUT Phase L1
4413 >DTT Trip L2 >Direct Transfer Trip INPUT Phase L2
4414 >DTT Trip L3 >Direct Transfer Trip INPUT Phase L3
4417 >DTT Trip L123 >Direct Transfer Trip INPUT 3ph L123
4421 DTT OFF Direct Transfer Trip is switched OFF
4422 DTT BLOCK Direct Transfer Trip is BLOCKED
4432 DTT TRIP 1p. L1 DTT TRIP command - Only L1
4433 DTT TRIP 1p. L2 DTT TRIP command - Only L2
4434 DTT TRIP 1p. L3 DTT TRIP command - Only L3
4435 DTT TRIP L123 DTT TRIP command L123
