Functions
6-118 7SA6 Manual
C53000-G1176-C156-2
6.6.3 Settings
Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings”.
Addr. Setting Title Setting Options Default Setting Comments
2101 FCT Telep. Dis. ON
PUTT (Z1B acceleration)
POTT
OFF
ON Teleprotection for Distance prot.
is
2102 Type of Line Two Terminals
Three Terminals
TwoTerminals TypeofLine
2103A Send Prolong. 0.00..30.00 sec 0.05 sec Time for send signal prolonga-
tion
2107A Delay for alarm 0.00..30.00 sec 10.00 sec Time Delay for Alarm
2108 Release Delay 0.000..30.000 sec 0.000 sec Time Delay for release after pik-
kup
2109A TrBlk Wait Time 0.00..30.00 sec; ∞ 0.04 sec Transient Block.: Duration exter-
nal flt.
2110A TrBlk BlockTime 0.00..30.00 sec 0.05 sec Transient Block.: Blk.T. after ext.
flt.
