SIPROTEC
®
4Devices
4-19
7SA6 Manual
C53000-G1176-C156-2
Settings for
Protective
Elements
Setting changes to individual protective elements and functions can be done using the
operator control panel on the SIPROTEC
®
4 device.
Other settings such as input/output and device configuration can be viewed from the
front panel, but not changed.
• Display the settings on the LCD using Main Menu → Settings →
e.g. Masking (I/O).
• Change settings such as date and time using Main Menu → Settings → Setup/
Extras.
Figure 4-14 Changing settings using the operator control panel — example
MAIN MENU 04/05
---------------------
Annunciation –> 1
Measurement –> 2
Control –> 3
Settings –> 4
Test/Diagnose –> 5
SETTINGS 10/11
---------------------
Device Config. –> 01
Masking (I/O) –> 02
P.System Data1 –> 03
Group A –> 04
Group B –> 05
Group C –> 06
Group D –> 07
Change Group –> 08
Osc.Fault Rec. –> 09
Setup/Extras –> 10
Device –> 11
---------------------
Active Group is: A
Note:
Changes to the individual settings are protected by Password No. 5 (Password for
single settings).
