5-17SA6 Manual
C53000-G1176-C156-2
Configuration 5
Configuration is the process of customizing the relay for the intended application.
To accomplish this, the following questions must be answered:
• Which functions do you need?
• Which information and measured quantities need to be retrieved via which inputs?
• Which information, measured data, and control actions need to be issued via which
outputs?
• Which user-definable functions need to be performed in CFC (Continuous Function
Chart)?
• Which information should be displayed on the front panel of the device?
• Which interfaces are to be used?
• Whichtimesourceistobeusedtosynchronizetheinternalclock?
This chapter describes in details how to configure the 7SA6.
5.1 Configuration of Functions 5-2
5.2 Configuration of the Binary Inputs and Outputs 5-9
5.3 Creating User Defined Functions with CFC 5-39
5.4 Establishing a Default Display 5-48
5.6 Serial Interfaces 5-54
5.7 Date and Time Stamping 5-58
