Functions
6-27
7SA6 Manual
C53000-G1176-C156-2
6.1.3.2 Information Overview
F.No. Alarm Comments
351 >CB Aux. L1 >Circuit breaker aux. contact: Pole L1
352 >CB Aux. L2 >Circuit breaker aux. contact: Pole L2
353 >CB Aux. L3 >Circuit breaker aux. contact: Pole L3
379 >CB 3p Closed >CB aux. contact 3pole Closed
380 >CB 3p Open >CB aux. contact 3pole Open
356 >Manual Close >Manual close signal
357 >Close Cmd. Blk >Block all Close commands from external
361 >FAIL:Feeder VT >Failure: Feeder VT (MCB tripped)
362 >FAIL:Bus VT >Failure: Busbar VT (MCB tripped)
366 >CB1 Pole L1 >CB1 Pole L1 (for AR,CB-Test)
367 >CB1 Pole L2 >CB1 Pole L2 (for AR,CB-Test)
368 >CB1 Pole L3 >CB1 Pole L3 (for AR,CB-Test)
410 >CB1 3p Closed >CB1 aux. 3p Closed (for AR, CB-Test)
411 >CB1 3p Open >CB1 aux. 3p Open (for AR, CB-Test)
371 >CB1 Ready >CB1 READY (for AR,CB-Test)
378 >CB faulty >CB faulty
381 >1p Trip Perm >Single-phase trip permitted from ext.AR
382 >Only 1ph AR >External AR programmed for 1phase only
383 >Enable ARzones >Enable all AR Zones / Stages
385 >Lockout SET >Lockout SET
386 >Lockout RESET >Lockout RESET
530 LOCKOUT LOCKOUT is active
501 Relay PICKUP Relay PICKUP
503 Relay PICKUP L1 Relay PICKUP Phase L1
504 Relay PICKUP L2 Relay PICKUP Phase L2
505 Relay PICKUP L3 Relay PICKUP Phase L3
506 Relay PICKUP E Relay PICKUP Earth
507 Relay TRIP L1 Relay TRIP command Phase L1
508 Relay TRIP L2 Relay TRIP command Phase L2
509 Relay TRIP L3 Relay TRIP command Phase L3
510 Relay CLOSE Relay GENERAL CLOSE command
511 Relay TRIP Relay GENERAL TRIP command
512 Relay TRIP 1pL1 Relay TRIP command - Only Phase L1
513 Relay TRIP 1pL2 Relay TRIP command - Only Phase L2
514 Relay TRIP 1pL3 Relay TRIP command - Only Phase L3
