Functions
6-54 7SA6 Manual
C53000-G1176-C156-2
3717 Dis.Loop L23<-> Distance Loop L23 selected non-direct.
3718 Dis.Loop L31<-> Distance Loop L31 selected non-direct.
3719 Dis. forward Distance Pickup FORWARD
3720 Dis. reverse Distance Pickup REVERSE
3741 Dis. Z1 L1E Distance Pickup Z1, Loop L1E
3742 Dis. Z1 L2E Distance Pickup Z1, Loop L2E
3743 Dis. Z1 L3E Distance Pickup Z1, Loop L3E
3744 Dis. Z1 L12 Distance Pickup Z1, Loop L12
3745 Dis. Z1 L23 Distance Pickup Z1, Loop L23
3746 Dis. Z1 L31 Distance Pickup Z1, Loop L31
3747 Dis. Z1B L1E Distance Pickup Z1B, Loop L1E
3748 Dis. Z1B L2E Distance Pickup Z1B, Loop L2E
3749 Dis. Z1B L3E Distance Pickup Z1B, Loop L3E
3750 Dis. Z1B L12 Distance Pickup Z1B, Loop L12
3751 Dis. Z1B L23 Distance Pickup Z1B, Loop L23
3752 Dis. Z1B L31 Distance Pickup Z1B, Loop L31
3755 Dis. Pickup Z2 Distance Pickup Z2
3758 Dis. Pickup Z3 Distance Pickup Z3
3759 Dis. Pickup Z4 Distance Pickup Z4
3760 Dis. Pickup Z5 Distance Pickup Z5
3771 Dis.Time Out T1 DistanceTime Out T1
3774 Dis.Time Out T2 DistanceTime Out T2
3777 Dis.Time Out T3 DistanceTime Out T3
3778 Dis.Time Out T4 DistanceTime Out T4
3779 Dis.Time Out T5 DistanceTime Out T5
3780 Dis.TimeOut T1B DistanceTime Out T1B
3781 Dis.TimeOut Tfw DistanceTime Out Forward PICKUP
3782 Dis.TimeOut Trv DistanceTime Out Reverse/Non-dir. PICKUP
3801 Dis.Gen. Trip Distance protection: General trip
3802 Dis.Trip 1pL1 Distance TRIP command - Only Phase L1
3803 Dis.Trip 1pL2 Distance TRIP command - Only Phase L2
3804 Dis.Trip 1pL3 Distance TRIP command - Only Phase L3
3805 Dis.Trip 3p Distance TRIP command Phases L123
3811 Dis.TripZ1/1p Distance TRIP single-phase Z1
3823 DisTRIP3p. Z1sf DisTRIP 3phase in Z1 with single-ph Flt.
3824 DisTRIP3p. Z1mf DisTRIP 3phase in Z1 with multi-ph Flt.
F.No. Alarm Comments
