Functions
6-62 7SA6 Manual
C53000-G1176-C156-2
care should however be taken that an arc fault on the local cable termination is inside
the set resistance of the first zone.
The resistance of the line need not be taken into consideration since it was considered
through the shape of the polygon, provided the line angle in address
1105 Line An-
gle
(see Subsection 6.1.3, margin heading General Line Data“) had been set cor-
rectly.
Example:
In the following example a maximum arc voltage of 8 kV is assumed for phase–phase
faults (line data as above). If the minimum primary fault current is assumed to be
1000 A this corresponds to 8
primary. This results in the following setting for the re-
sistance reach of the first zone:
primary
:
or secondary
:
Only half the arc resistance was applied in the equation, as it is added to the
loop im-
pedance and therefore only half the arc resistance appears in the
per phase imped-
ance.
A separate resistance margin can be set for earth faults. An arc resistance of 6
and
a tower footing resistance of 12
is assumed. This results in the following
primary
:
or secondary
:
In this case the least favourable condition was assumed, whereby the earth current
does not return via the measuring point. If all the earth current, or a portion of the earth
current flows via the measuring point, the measured resistance decreases. If the in-
feed comes from the remote end, the measured resistance may be increased.
Independent Zones
Z1 up to Z5
By means of the setting parameter MODE each zone can be set Forward or Reverse
or Non-Directional (Address 1301 Op. mode Z1, 1311 Op. mode Z2, 1321
Op. mode Z3
, 1331 Op. mode Z4 and 1341 Op. mode Z5). This allows any com-
bination of forward, reverse or non-directional graded zones, for example on trans-
formers, generators or bus couplers. In the fifth zone different reach in the X direction
can be set for forward or reverse. Zones that are not required, are set
Inactive.
The values derived from the grading coordination chart are set for each of the required
zones. The setting parameters are grouped for each zone. For the first zone, Z1, these
are the parameters
R(Z1) (address 1302) for the R intersection of the polygon appli-
cable to phase-phase faults,
X(Z1) (address 1303) for the X intersection of the poly-
gon (reach),
RE(Z1) (address 1304) for the R intersection of the polygon applicable
to phase-earth faults as well as the relevant delay time settings.
R1
prim
1
2
---
R
arc
1
2
---
8 4 ===
R1
sec
N
CT
N
VT
----------
R1
prim
600 A/5 A
110 kV/0.1 kV
--------------------------------------
4 0.44 == =
R1E
prim
R
arc
R
tower
+ 6 12 + 18 ===
R1E
sec
N
CT
N
VT
----------
R1
prim
600 A/5 A
110 kV/0.1 kV
--------------------------------------
18 1.96
== =
