Siemens siprotec 7SA6 User Manual

Functions
6-136 7SA6 Manual
C53000-G1176-C156-2
3123 3I0>> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
3124 3I0>> SOTF-Trip NO
YES
NO Instantaneous trip after Swit-
chOnToFault
3125 3I0>> InrushBlk NO
YES
NO Inrush Blocking
3130 Op. mode 3I0> Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3131 3I0> 0.05..25.00 A 1.00 A 3I0> Pickup
3131 3I0> 0.003..25.000 A 1.000 A 3I0> Pickup
3132 T 3I0> 0.00..30.00 sec; ∞ 0.90 sec T 3I0> Time Delay
3133 3I0> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
3134 3I0> SOTF-Trip NO
YES
NO Instantaneous trip after Swit-
chOnToFault
3135 3I0> InrushBlk NO
YES
NO Inrush Blocking
3140 Op. mode 3I0p Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3141 3I0p PICKUP 0.05..25.00 A 1.00 A 3I0p Pickup
3141 3I0p PICKUP 0.003..25.000 A 1.000 A 3I0p Pickup
3147 Add.T-DELAY 0.00..30.00 sec; ∞ 1.20 sec Additional Time Delay
3148 3I0p Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
3149 3I0p SOTF-Trip NO
YES
NO Instantaneous trip after Swit-
chOnToFault
3150 3I0p InrushBlk NO
YES
NO Inrush Blocking
3142 3I0p MinT-DELAY 0.00..30.00 sec 1.20 sec 3I0p Minimum Time Delay
3143 3I0p Time Dial 0.05..3.00 sec; ∞ 0.50 sec 3I0p Time Dial
3144 3I0p Time Dial 0.50..15.00; ∞ 5.00 3I0p Time Dial
3145 3I0p Time Dial 0.05..15.00 sec; ∞ 1.35 sec 3I0p Time Dial
3146 3I0p MaxT-DELAY 0.00..30.00 sec 5.80 sec 3I0p Maximum Time Delay
3151 IEC Curve Normal Inverse
Very Inverse
Extremely Inverse
Long time inverse
Normal Inverse IEC Curve
Addr. Setting Title Setting Options Default Setting Comments
