vated, the pole which has been tripped is also indicated during single-pole tripping (re-
fer also to Sub-section 6.22.4 Overall Tripping Logic of the Device).
Table 6-11 Fault detection annunciations of the overcurrent protection
Internal event Figure Output alarm FNo
I>> Pickup L1
I> Pickup L1
Ip Pickup L1
I-STUB Pickup L1
6-91
6-92
6-94
O/C Pickup L1 7162
I>> Pickup L2
I> Pickup L2
Ip Pickup L2
I-STUB Pickup L2
6-91
6-92
6-94
O/C Pickup L2 7163
I>> Pickup L3
I> Pickup L3
Ip Pickup L3
I-STUB Pickup L3
6-91
6-92
6-94
O/C Pickup L3 7164
I>> Pickup E
I> Pickup E
Ip Pickup E
I-STUB Pickup E
6-91
6-92
6-94
O/C Pickup E 7165
I>> Pickup L1
I>> Pickup L2
I>> Pickup L3
I>> Pickup E
6-91
6-91
6-91
6-91
O/C PICKUP I>> 7191
I> Pickup L1
I> Pickup L2
I> Pickup L3
I> Pickup E
O/C PICKUP I> 7192
Ip Pickup L1
Ip Pickup L2
Ip Pickup L3
Ip Pickup E
6-92
6-92
6-92
6-92
O/C PICKUP Ip 7193
I-STUB Pickup L1
I-STUB Pickup L2
I-STUB Pickup L3
I-STUB Pickup E
6-94
6-94
6-94
6-94
I-STUB PICKUP 7201
(all pick-ups) O/C PICKUP 7161
