Functions
6-176 7SA6 Manual
C53000-G1176-C156-2
7106 >BLOCK O/C Ip >BLOCK Backup OverCurrent Ip
7110 >O/C InstTRIP >Backup OverCurrent InstantaneousTrip
7130 >BLOCK I-STUB >BLOCK I-STUB
7131 >I-STUB ENABLE >Enable I-STUB-Bus function
7151 O/C OFF Backup O/C is switched OFF
7152 O/C BLOCK Backup O/C is BLOCKED
7153 O/C ACTIVE Backup O/C is ACTIVE
7161 O/C PICKUP Backup O/C PICKED UP
7162 O/C Pickup L1 Backup O/C PICKUP L1
7163 O/C Pickup L2 Backup O/C PICKUP L2
7164 O/C Pickup L3 Backup O/C PICKUP L3
7165 O/C Pickup E Backup O/C PICKUP EARTH
7171 O/C PU only E Backup O/C Pickup - Only EARTH
7172 O/C PU 1p. L1 Backup O/C Pickup - Only L1
7173 O/C Pickup L1E Backup O/C Pickup L1E
7174 O/C PU 1p. L2 Backup O/C Pickup - Only L2
7175 O/C Pickup L2E Backup O/C Pickup L2E
7176 O/C Pickup L12 Backup O/C Pickup L12
7177 O/C Pickup L12E Backup O/C Pickup L12E
7178 O/C PU 1p. L3 Backup O/C Pickup - Only L3
7179 O/C Pickup L3E Backup O/C Pickup L3E
7180 O/C Pickup L31 Backup O/C Pickup L31
7181 O/C Pickup L31E Backup O/C Pickup L31E
7182 O/C Pickup L23 Backup O/C Pickup L23
7183 O/C Pickup L23E Backup O/C Pickup L23E
7184 O/C Pickup L123 Backup O/C Pickup L123
7185 O/C PickupL123E Backup O/C Pickup L123E
7191 O/C PICKUP I>> Backup O/C Pickup I>>
7192 O/C PICKUP I> Backup O/C Pickup I>
7193 O/C PICKUP Ip Backup O/C Pickup Ip
7201 I-STUB PICKUP O/C I-STUB Pickup
7211 O/C TRIP Backup O/C General TRIP command
7212 O/C TRIP 1p.L1 Backup O/C TRIP - Only L1
7213 O/C TRIP 1p.L2 Backup O/C TRIP - Only L2
7214 O/C TRIP 1p.L3 Backup O/C TRIP - Only L3
7215 O/C TRIP L123 Backup O/C TRIP Phases L123
F.No. Alarm Comments
