Functions
6-184 7SA6 Manual
C53000-G1176-C156-2
Voltage Settings The displacement voltage is the pickup threshold of the earth fault detection and is set
in address
3002 3U0>.
If the displacement voltage U
en
of the voltage transformer set is directly connected to
the fourth voltage measuring input U
4
of the device and if this was predefined during
the configuration, the device will use this voltage, multiplied by the factor
Uph /
Udelta
(address 211). For the usual transformation of the voltage transformer with
e–n–winding
the factor is set to 1,73 (
√3) (see also Subsection 6.1.1, margin heading “Voltage
Transformer Connection”). In case of a complete displacement of a healthy voltage tri-
angle the displacement voltage has a value that is
√3 times the phase-to-phase volt-
age.
If no displacement voltage is connected to the device, the device calculates the mon-
itored voltage from the total of the voltages:
3
⋅U
0
=|U
L1
+U
L2
+U
L3
|.
In case of a complete displacement of a healthy voltage triangle the displacement volt-
age also has a value that is
√3 times the phase-to-phase voltage.
Since, in case of earth faults in isolated or resonant-earthed systems, the complete
displacement voltage emerges, the setting value is uncritical; it should approx. be be-
tween 40 % to 50 % of the displacement voltage: for U
N
= 100 V therefore between
70Vto90V.
The earth fault is only recognized and announced if the displacement voltage has
been “present” for the time set in
T Sens.E/F (address 3006). This stabilizing period
is also enabled if earth fault conditions change (e.g. change of direction).
If tripping is also required for earth faults (address
3001, Sens. Earth Flt = ON),
adelaytimecanbesetinaddress
3007 T 3U0>.
For phase determination Uph-e min (address 3003) is the criterion for the earth-
faulted phase, when simultaneously the other two phase voltages have exceeded
Uph-e max (address 3004). Accordingly, Uph-e min must be set lower than the
minimum operational phase-earth voltage. This setting is, however, also not critical,
40 V (factory setting) should always be adequate.
Uph-e max must lie above the max-
imum operational phase-earth voltage, but below the minimum operational phase-
phase voltage, therefore, for example, 75 V at U
N
= 100 V. The identification of the
faulty phase is a further precondition for annunciation of an earth fault.
Directional
Determination
For determination of the direction of the earth fault, in principle, the threshold current
3I0> (address 3005) should be set as high as possible to prevent faulty operation due
to asymmetrical currents in the network and the current transformers (particularly in
Holmgreen connection). Dependent upon the treatment of the network star point, the
magnitude of the capacitive earth fault current (for isolated networks) or the wattmetric
residual current (for compensated networks) is decisive.
In
isolated networks an earth fault in a cable will allow the total capacitive earth fault
currents of the entire electrically connected network, with the exception of the faulted
cable itself, to flow through the measuring point. It is normal to use half the value of
this earth fault current as the threshold value.
Example:
A 25 kV bus-bar feeds seven cable circuits. Each circuit has a current trans-
former set 300 A/1 A. The earth fault current is 2.5 A/km. The cables might be as fol-
lows:
U
Nprim
3
------------------
U
Nsec
3
----------------
U
Nsec
3
----------------
⁄⁄
