Siemens siprotec 7SA6 User Manual

Functions
6-2137SA6 Manual
C53000-G1176-C156-2
3465 2.AR Tdead 2Flt 0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3466 2.AR Tdead 3Flt 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3467 2.AR Tdead1Trip 0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3468 2.AR Tdead3Trip 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3469 2.AR: Tdead EV. 0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3470 2.AR: CB? CLOSE YES
NO
NO CB ready interrogation before
reclosing
3471 2.AR SynRequest YES
NO
NO Request for synchro-check after
3pole AR
3472 3.AR: START YES
NO
NO AR start allowed in this cycle
3473 3.AR: T-ACTION 0.01..300.00 sec; ∞ 0.20 sec Action time
3475 3.AR Tdead 1Flt 0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3476 3.AR Tdead 2Flt 0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3477 3.AR Tdead 3Flt 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3478 3.AR Tdead1Trip 0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3479 3.AR Tdead3Trip 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3480 3.AR: Tdead EV. 0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3481 3.AR: CB? CLOSE YES
NO
NO CB ready interrogation before
reclosing
3482 3.AR SynRequest YES
NO
NO Request for synchro-check after
3pole AR
3483 4.AR: START YES
NO
NO AR start allowed in this cycle
3484 4.AR: T-ACTION 0.01..300.00 sec; ∞ 0.20 sec Action time
3486 4.AR Tdead 1Flt 0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3487 4.AR Tdead 2Flt 0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3488 4.AR Tdead 3Flt 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3489 4.AR Tdead1Trip 0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3490 4.AR Tdead3Trip 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3491 4.AR: Tdead EV. 0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3492 4.AR: CB? CLOSE YES
NO
NO CB ready interrogation before
reclosing
3493 4.AR SynRequest YES
NO
NO Request for synchro-check after
3pole AR
3431 DLC or RDT Without
ReducedDeadTime(RDT)
Dead Line Check (DLC)
Without Dead Line Check or Reduced
Dead Time
3420 AR w/ DIST. YES
NO
YES AR with distance protection
Addr. Setting Title Setting Options Default Setting Comments
