Functions
6-216 7SA6 Manual
C53000-G1176-C156-2
2783 AR is blocked AR: Auto-reclose is blocked
2784 AR not ready AR: Auto-reclose is not ready
2787 CB not ready AR: Circuit breaker not ready
2788 AR T-CBreadyExp AR: CB ready monitoring window expired
2796 AR on/off BI AR: Auto-reclose ON/OFF via BI
2801 AR in progress AR in progress
2809 AR T-Start Exp AR: Start-signal monitoring time expired
2810 AR TdeadMax Exp AR: Maximum dead time expired
2818 AR evolving Flt AR: Evolving fault recognition
2820 AR Program1pole AR is set to operate after 1p trip only
2821 AR Td. evol.Flt AR dead time after evolving fault
2839 AR Tdead 1pTrip AR dead time after 1pole trip running
2840 AR Tdead 3pTrip AR dead time after 3pole trip running
2841 AR Tdead 1pFlt AR dead time after 1phase fault running
2842 AR Tdead 2pFlt AR dead time after 2phase fault running
2843 AR Tdead 3pFlt AR dead time after 3phase fault running
2844 AR 1stCyc. run. AR 1st cycle running
2845 AR 2ndCyc. run. AR 2nd cycle running
2846 AR 3rdCyc. run. AR 3rd cycle running
2847 AR 4thCyc. run. AR 4th or higher cycle running
2848 AR ADT run. AR cycle is running in ADT mode
2851 AR CLOSE Cmd. AR: Close command
2852 AR Close1.Cyc1p AR: Close command after 1pole, 1st cycle
2853 AR Close1.Cyc3p AR: Close command after 3pole, 1st cycle
2854 AR Close 2.Cyc AR: Close command 2nd cycle (and higher)
2861 AR T-Recl. run. AR: Reclaim time is running
2862 AR successful AR successful
2864 AR 1p Trip Perm AR: 1pole trip permitted by internal AR
2865 AR Sync.Request AR: Synchro-check request
2871 AR TRIP 3pole AR: TRIP command 3pole
2889 AR 1.CycZoneRel AR 1st cycle zone extension release
2890 AR 2.CycZoneRel AR 2nd cycle zone extension release
2891 AR 3.CycZoneRel AR 3rd cycle zone extension release
2892 AR 4.CycZoneRel AR 4th cycle zone extension release
2893 AR Zone Release AR zone extension (general)
2894 AR Remote Close AR Remote close signal send
F.No. Alarm Comments
