Hardware and Connections
2-14
7SA6 Manual
C53000-G1176-C156-2
noted that all screws on the terminal module must be screws in before snapping the
cover on. The terminal covering cap can simply be removed with a screw driver 6x1.
There are two types of covering caps, as shown in Figure 2-13. Ordering information
is provided in Section A.1 in the Appendix.
Figure 2-13 Covering caps for terminal blocks with screw terminals
Covering cap for
18 terminal voltage
Covering cap for
12 terminal voltage
connection terminal block or 8 Terminal Current
connection terminal block
SIEMENS
C73334-A1-C31-1
>PCGF<
:AMP
SIEMENS
C73334-A1-C32-1
>PCGF<
:AMP
